Manufacturing Companies for Slim Led Linear Light - Premline linear lights direct version – Sundopt

Short Description:


Product Detail

Product Tags

Related Video

Feedback (2)

With this motto in mind, we have turn out to be amongst probably the most technologically innovative, cost-efficient, and price-competitive manufacturers for Big Square Ceiling Light, Led Light Ceiling Square, Surface Mounted Led Panel Lights, For further information, please do not hesitate to contact us. All inquiries from you will be highly appreciated.
Manufacturing Companies for Slim Led Linear Light - Premline linear lights direct version – Sundopt Detail:

linear pendant light
Linear light

Specifications Premline linear lights direct version
Size 1200mm, 1500mm, 3000mm
Color Matt White(Ral 9016),Matt Black(RAL 9005)
Material Housing: Aluminium Diffusor: Microprism PMMA End cap: Aluminium
Lumen 2400lm, 3200lm@1200mm, 3000lm, 4000lm@1500mm, 6000lm, 8000lm@3000mm,
CCT 3000k, 4000k,3000-6500k tunable
CRI >80Ra, >90Ra
UGR <22
SDCM ≤3
Efficacy 120lm/W
Wattage 17W, 25W@1200mm, 25W, 31W@1500mm, 50W, 62W@3000mm
Voltage 200-240V
THD <15%
Lifespan 50000H(L90, Tc=55°C)
IP Protection IP20
Specifications Premline linear lights indirect/direct version
Size 1200mm,1500mm,3000mm
Color Matt White(Ral 9016),Matt Black(RAL 9005)
Material Housing:Aluminium Diffusor:Microprism PMMA End cap:Aluminium
Lumen 4000lm(1600lm↑+2400lm↓)@1200mm,5000lm(2000lm↑+3000lm↓)@1500mm,10000lm(4000lm↑+6000lm↓)@3000mm,
CCT 3000k,4000k,3000-6500k tunable
CRI >80Ra, >90Ra
UGR <19
SDCM ≤3
Efficacy 130lm/W
Wattage 31w@1200mm, 38w@1500mm, 77w@3000mm
Voltage 200-240V
THD <15%
Lifespan 50000H(L90, Tc=55°C)
IP Protection IP20

linear light cover

Architects need an elegant lighting with outstanding performance, helping them in design side to enhance the spatial experience. Investors want luminiares in higher efficiency and durability. Easy installation and replacement are installers’ concerns. Employees expect the environment to increase well-being and improve productivity.

Premline could meet all sets of requirements and act as an ideal lighting solution for office and education areas.

Seamless connection and Elegant design

Premline linear lights are different in special connect way to archive seamless connection and no light leakage.Premline appear elegant due to its stylish outline with no visibel screws,compatible with architectural aesthetics.

linear light fixture
Linear light prismatic

Microprism glare control diffusor

Thanks to innovative optical technology, Premline could produce glare-free lights with micoprism diffusor. Glare-free, UGR<13,l65<1500 cd/m².

Five-year warranty and strong R&D team

Providing high quality products with a five-year warranty.Over 30 professional and experienced engineers in R&D team, strongly support Sundopt unique and special OEM/ODM strategy.

led linear light

Grille line light

Modular and elegant design

The split modular design of the linear light facilitates installation and transport. Flexible stocking solutions are available for the SKD.

Uniform indirect/direct light

Viewline Linear has two types, direct type and indirect-indirect type. Direct lights provide services for the workstations, while indirect lights can enhance the uniformity of the entire task area, thereby creating a balanced luminous environment through the reflection of the ceiling.


Grille line light-4

Quality control
Grille single row line light-3
zhengshu-1
zhengshu-4
zhengshu-5
zhengshu-3
zhengshu-2


Product detail pictures:

Manufacturing Companies for Slim Led Linear Light - Premline linear lights direct version – Sundopt detail pictures

Manufacturing Companies for Slim Led Linear Light - Premline linear lights direct version – Sundopt detail pictures

Manufacturing Companies for Slim Led Linear Light - Premline linear lights direct version – Sundopt detail pictures

Manufacturing Companies for Slim Led Linear Light - Premline linear lights direct version – Sundopt detail pictures

Manufacturing Companies for Slim Led Linear Light - Premline linear lights direct version – Sundopt detail pictures

Manufacturing Companies for Slim Led Linear Light - Premline linear lights direct version – Sundopt detail pictures

Manufacturing Companies for Slim Led Linear Light - Premline linear lights direct version – Sundopt detail pictures
